UPO1104 Digital Oscilloscope – Precision and Performance
Description The UPO1104 digital oscilloscope, part of the advanced UPO1000 series by UNI-T, delivers high precision and performance for various technical and industrial applications. It features a bandwidth of 100MHz and a real-time sampling rate of up to 2GSa/s, ensuring accurate signal capture. The oscilloscope is equipped with four channels and offers a variety of functionalities, including extensive bus analysis and auto measurement capabilities.
Key Features
- Bandwidth: 100MHz
- Channels: 4 standard channels
- Sampling Rate: Up to 2 GSa/s
- Waveform Capture Rate: 150,000 wfm/s and up to 500,000 wfm/s with Fast Acquire
- Storage Depth: 56 Mpts
- Vertical Range: 8-bit resolution
- Vertical Scale: 1 MΩ: 500μV/div to 20 V/div
- Gain Accuracy:
- <10mV: ±4.0% full scale
- ≥10mV: ±3.0% full scale
- Time Base Range: 2 ns/div to 1000 s/div
- Frequency Meter: 7-digit resolution
- Bus Analysis: Supports RS232/UART, I2C, SPI
- Auto Measurement: 36 types
- Waveform Recording: Up to 120,000 frames
- FFT Points: 1Mpts for detailed frequency analysis
- Interface: USB Host, USB Device, LAN
- Display: 7-inch TFT-LCD with 800×480 resolution
Why You Should Buy The UPO1104 digital oscilloscope is designed to meet the needs of professionals and enthusiasts in fields such as communication, semiconductor, computer and integrated circuit design, instrumentation, industrial electronics, consumer electronics, automotive electronics, field maintenance, and research & development. Its robust design and comprehensive features ensure precise and reliable measurements, making it an indispensable tool for various technical and industrial applications.
Applications
- Communication Systems: Ideal for testing and troubleshooting
- Semiconductor Development: Provides accurate testing and measurement capabilities
- Computer and IC Design: Essential for design, testing, and debugging processes
- Industrial and Consumer Electronics: Versatile usage in multiple electronic applications
- Automotive Electronics: Supports diagnostics and maintenance
- Field Maintenance: Portable and reliable for on-site testing and maintenance
- R&D and Education: Perfect for educational purposes and research projects
The UPO1104 digital oscilloscope offers advanced measurement capabilities, making it a top choice for professionals across various industries. For more information, please visit the UNI-T website.
