UNI-T UT8804E Benchtop Digital Multimeter- True Rms

Product Overview: The UNI-T UT8804E is a high-performance desktop digital multimeter designed to provide precise and reliable measurements across a wide range of parameters. Featuring a maximum display value of 60000 and equipped with both automatic and manual range adjustment options, this multimeter delivers exceptional versatility. Its advanced circuit design, incorporating large-scale (LSI) analog-to-digital converters and a microprocessor, ensures outstanding performance. The UT8804E is suitable for measuring AC/DC voltage, AC/DC current, resistance, conductivity, diodes, line continuity, capacitance, temperature, frequency, pulse width, and more.

Key Features:

• True RMS Measurement: Ensures accurate measurement of AC signals, critical for precise diagnostics and testing.
• High Resolution Display: 60000 counts display with a 4.3-inch color TFT screen for clear and detailed measurement readouts.
• Versatile Measurement Capabilities: Measures AC/DC voltage, AC/DC current, resistance, continuity, diodes, capacitance, temperature, frequency, pulse width, and more.
• Data Storage: Capable of recording and reading up to 20,000 data records for comprehensive analysis.
• Peak Value Detection: Captures peak values for dynamic signal assessment.
• Trend Graph Capture: Visualizes measurement trends over time, enhancing data interpretation.
• Automatic/Manual Range Selection: Offers flexibility in measurement range adjustment to suit different testing requirements.
• Relative Value Measurement: Facilitates comparison measurements for enhanced analysis.
• Multi-Level Display: Provides versatile and clear display of measurement results, including trend graphs and meter readings.
• Overload Protection: Features robust protection for input terminals to ensure safe operation.
• USB Interface: Enables easy data transfer and connectivity with computers for advanced data analysis.

Technical Specifications:

• Maximum Voltage (Input to COM Terminal): 1000V (DC/AC)
• Input Terminal Protection (10A): (CE) F1, 11A H/1000V, fuse Ø 10×38 mm
• Input Terminal Protection (μA, mA): (CE) F2, F600mA/1000V, fuse Ø 6×32 mm
• Display: 4.3-inch color TFT with full icon display; maximum value of 60000
• Refresh Rate: 2-3 times per second
• Range Selection: Automatic/Manual
• Polarity Display: Automatic
• Overload Display: OL

Package Contents:

• Test Cables: High-quality cables for accurate measurements.
• Crocodile Clips: Versatile clips for secure connections.
• Temperature Probe (Type K): 2 pieces for temperature measurements.
• Power Cable (AC 220V): Reliable power source for uninterrupted operation.
• Application on CD: Software for advanced data analysis.
• USB Cable: Facilitates easy data transfer and connectivity.
• Calibration/Conformity Report: Ensures the device meets stringent quality standards.

Why You Should Buy: The UT8804E digital multimeter is designed to provide precise and reliable measurements with a host of advanced features. Its true RMS measurement capability ensures accurate readings of AC signals, while the high resolution and rapid reading speed support detailed and fast data collection. The extensive data storage and robust connectivity options make it suitable for both standalone use and integration into larger automated test systems. Whether you are involved in design, manufacturing, or education, the UT8804E offers the performance and flexibility needed for a wide range of applications.

Lifestyle Integration:

The UNI-T UT8804E is ideal for engineers, technicians, and educators who require a versatile and reliable benchtop multimeter. Whether you are working in a lab, conducting complex diagnostics, or teaching electronics, this multimeter offers the precision and features needed to excel in your tasks. Its user-friendly features, robust protection, and versatile display enhance the user experience, making it a valuable addition to any technical setup.
